Hastelloy G-35
UNS N06035
Catalog
Arialloy are carefully crafted using only the finest materials. Our production team offers superior craftsmanship with over 10 years of experience working with hastelloy g35 tubes / sheets / wires / bars / fittings
Hastelloy G35 Material Properties
UNS N06035 Overview
Explore the chemical composition, corrosion resistance, mechanical properties, and temperature characteristics of hastelloy g35 for optimal resistance, strength, and stability
Hastelloy G-35 Chemical Composition
Hastelloy G35 Material Properties Overview
As a manufacturer and supplier in China, Arialloy offers competitively priced hastelloy G35 products.
Hastelloy G35 (UNS N06035) is an austenitic nickel alloy containing approximately 33.2% chromium and 8.1% molybdenum. Nickel forms the balance, while iron is limited to 2% maximum. Its high chromium content contributes resistance to oxidizing environments, and molybdenum provides solid solution strengthening while supporting corrosion resistance. The alloy combines a predominantly austenitic structure with good ductility in the solution annealed condition. Its resistance to wet process phosphoric acid is a defining characteristic, together with resistance to localized corrosion in the presence of chlorides. Solution annealing and rapid cooling help retain alloying elements in the matrix and limit the formation of detrimental secondary phases. This metallurgical condition supports both corrosion performance and subsequent fabrication.
The material can be formed and welded using established techniques for nickel alloys. Cold deformation increases strength and hardness, so substantial forming may require intermediate annealing to restore ductility. Suitable joining methods include gas tungsten arc, gas metal arc, and shielded metal arc welding, with matching G35 welding consumables available for these processes.
Hastelloy G-35 Corrosion Resistance
Hastelloy G35 offers excellent resistance to wet process phosphoric acid, nitric acid, and mixtures containing nitric acid. It also resists chloride induced pitting, crevice corrosion, and stress corrosion cracking.
The alloy has strong resistance to selective dissolution in hot sodium hydroxide. Its resistance to reducing acids is moderate, with performance depending on acid concentration and temperature. In boiling 45% magnesium chloride testing, stressed samples showed no cracking after 1,008 hours. This result describes the test conditions and does not imply immunity in every chloride environment.
Hastelloy G35 Mechanical Properties
In the solution annealed condition, hastelloy G35 combines strength with high ductility. Typical room temperature results for 3.2 mm Sheet include a tensile strength of 738 MPa, a 0.2% offset yield strength of 345 MPa, and 60% elongation. Cold working raises strength and hardness while reducing the ductility available for further deformation.
Hastelloy G-35 Temperature Characteristics
Hastelloy G35 conducts heat more readily as temperature rises, while its elastic modulus decreases. Typical thermal conductivity increases from 10 W/m·K at room temperature to 23 W/m·K at 600°C, with dynamic elastic modulus falling from 204 to 174 GPa. Solution annealing at approximately 1121°C (2050°F), followed by rapid cooling, restores the desired metallurgical condition.
Extended exposure to elevated temperatures can promote secondary phase precipitation, affecting ductility and corrosion resistance. The annealing temperature does not define a continuous service limit.
Hastelloy G35 Products
Nickel Alloy G-35 Product Types
With advanced equipment and expert craftsmanship, we create durable, high performance nickel alloy g35 products tailored to each project’s needs
Hastelloy G-35 Data Sheet
Hastelloy Alloy G35 Data Sheet
Access / download the hastelloy g-35 data sheet to gain in depth insights into precise physical and processing parameters
ensuring the selection of the optimal nickel alloy material for your project
Physical Properties
| Density | g/cm3 | 8.22 | |
|---|---|---|---|
| lb/in.3 | 0.297 | ||
| Melting Range | °F | 2430 - 2482 | |
| °C | 1332 - 1361 | ||
Mechanical Properties
| Form | Thickness / Bar Diameter | Test Temperature | Yield Strength (0.2% Offset) | Tensile Strength | Elongation | ||||
|---|---|---|---|---|---|---|---|---|---|
| in | mm | °F | °C | ksi | MPa | ksi | MPa | % | |
| Sheet | 0.125 | 3.2 | RT | RT | 50 | 345 | 107 | 738 | 60 |
| Sheet | 0.125 | 3.2 | 200 | 93 | 43 | 296 | 101 | 696 | 63 |
| Sheet | 0.125 | 3.2 | 400 | 204 | 36 | 248 | 93 | 641 | 64 |
| Sheet | 0.125 | 3.2 | 600 | 316 | 31 | 214 | 89 | 614 | 70 |
| Sheet | 0.125 | 3.2 | 800 | 427 | 30 | 207 | 86 | 593 | 74 |
| Sheet | 0.125 | 3.2 | 1000 | 538 | 27 | 186 | 80 | 552 | 68 |
| Sheet | 0.125 | 3.2 | 1200 | 649 | 26 | 179 | 75 | 517 | 68 |
| Plate | 0.5 | 12.7 | RT | RT | 46 | 317 | 100 | 689 | 72 |
| Plate | 0.5 | 12.7 | 200 | 93 | 41 | 283 | 97 | 669 | 74 |
| Plate | 0.5 | 12.7 | 400 | 204 | 33 | 228 | 88 | 607 | 75 |
| Plate | 0.5 | 12.7 | 600 | 316 | 29 | 200 | 82 | 565 | 71 |
| Plate | 0.5 | 12.7 | 800 | 427 | 30 | 207 | 78 | 538 | 77 |
| Plate | 0.5 | 12.7 | 1000 | 538 | 26 | 179 | 72 | 496 | 75 |
| Plate | 0.5 | 12.7 | 1200 | 649 | 24 | 165 | 68 | 469 | 74 |
| Bar | 1 | 25.4 | RT | RT | 46 | 317 | 103 | 710 | 66 |
| Bar | 1 | 25.4 | 200 | 93 | 41 | 283 | 98 | 676 | 70 |
| Bar | 1 | 25.4 | 400 | 204 | 35 | 241 | 89 | 614 | 71 |
| Bar | 1 | 25.4 | 600 | 316 | 30 | 207 | 84 | 579 | 71 |
| Bar | 1 | 25.4 | 800 | 427 | 31 | 214 | 81 | 558 | 73 |
| Bar | 1 | 25.4 | 1000 | 538 | 28 | 193 | 75 | 517 | 72 |
| Bar | 1 | 25.4 | 1200 | 649 | 23 | 159 | 69 | 476 | 71 |
Hastelloy G35 Standards
UNS N06035 Specifications & Standards
From production to inspection, we meet strict quality standards, addressing tolerance and chemical composition needs
ASTM B622
Seamless Pipe & Tube
ASTM B619
Welded Pipe & Tube
ASTM B626
Welded Pipe & Tube
ASTM B366
Fittings
ASTM B462
Fittings and Forgings
ASTM B574
Billet, Rod and Bar
ASTM B564
Forgings
ASTM B575
Plate, Sheet and Strip
AWS A5.14 ERNiCrMo-22
Filler Metal
AWS A5.11 ENiCrMo-22
Welding Electrode
Hastelloy G-35 SHOW
Nickel Alloy G35 Showcase
From initial samples to large scale production, we supply high quality hastelloy g-35 products and help you achieve your manufacturing goals.
Upload Your Requirements
To begin, provide your contact details with the product type, dimensions, quantity, and required standards. If you have CAD drawings, specifications, or special tolerance requirements, please upload them
Receive a Quote & Design Review
Within 12 hours, we’ll send you a detailed quote and (custom) design for manufacturability (DFM) feedback. This ensures the cost feasibility of your custom project and gives you a clear idea of the costs involved
Confirm Your Order & Begin Production
Once you approve the quote and design, your project will enter our production queue the morning after we receive your confirmation
Shipping & Delivery
On average, custom production orders ship within 20–45 business days. In stock products and samples ship within 48 hours
Just 4 Steps
Custom Hastelloy G35 Quotation Process
From detailed consultation to final delivery, we make custom hastelloy g-35 product orders simple and convenient. With exceptional customer service, we anticipate your needs, provide professional solutions, and ensure on time delivery
Hastelloy G35 Supplier - Arialloy
From Production to Quality Control, Every Step Tailored to Perfection
Arialloy hastelloy alloy g-35 manufacturer has always been at the forefront of the industry. With its unremitting pursuit of quality, precision, and professional solutions, Arialloy has gradually established a complete production system and rapid supply capabilities. By continuously improving manufacturing processes, adopting cutting edge equipment, and adhering to strict quality control, Arialloy ensures that every product meets the highest requirements for durability, precision, and international standards
Hastelloy G-35 Applications
UNS N06035 Alloy Solutions
We serving diverse industries, focus on strict quality control and full scale production, turning your vision into reality with professional expertise and attention to detail
Hastelloy G35 Knowledge
Nickel Alloy G-35 Wiki
Arialloy explores with you every factor that influences your choice
including chemical composition, mechanical properties, temperature characteristics, price, and manufacturing process
Inconel 686 VS Inconel 686
This addition of aluminum in Inconel 601 promotes the formation of a stable aluminum oxide (Al₂O₃) layer on the surface at high temperatures. This protective film significantly
Inconel 600 VS Inconel 601
Inconel Alloy 600 (UNS N06600 / W.Nr. 2.4816) is a classic nickel-chromium-iron superalloy designed for excellent corrosion resistance and mechanical stability at elevated temperatures. It combines a
Monel 400 VS Inconel 600
As this table shows, the high nickel and copper content in Monel 400 ensures excellent resistance against attack by seawater and many acids, while the significant chromium
More Hastelloy Grades
Hastelloy Alloy Grades
Explore the full range of hastelloy alloys to expand your material choices and ensure you find the perfect nickel alloy
Custom Hastelloy G-35 FAQs
Our team of experts is here to support you every step of the way, helping transform your vision into reality. Explore FAQs for related support
To get your hastelloy g35 order started, send your requirements to sales@arialloy.com or submit the form below. We will review your specifications and send you a detailed quotation. Once you approve the offer, send us your PO. We will then issue the PI for payment. Production begins after the prepayment is received, and we will notify you when the material is completed.
After receiving your hastelloy g35 requirements, we generally send a corresponding quote within 24 hours. If there is not enough information to prepare the quote or we cannot provide one, we will contact you promptly.
Hastelloy G-35 is normally quoted FOB, and the customer therefore has the option to appoint a freight forwarder for transportation. We will cooperate with your nominated forwarder on local handling. If you prefer us to coordinate everything related to shipping, we can arrange the transportation and confirm its cost.
One of the key cost drivers for hastelloy g35 is the price of the raw metals required for its production. Market changes affecting nickel, chromium, molybdenum, and iron and other metallic materials can therefore result in noticeable movements in the alloy’s price.
We carry out our own hastelloy g35 smelting with a diversified furnace fleet of more than 30 units. Vacuum smelting and electroslag remelting are both available, with furnace capacities of 50 kg, 200 kg, 1,000 kg, and 5,000 kg. This flexibility allows us to handle orders of different sizes, including smaller batches.
Certainly, we make the hastelloy g35 material test report available before shipping. The report follows applicable industry standards and records the material standard, chemical composition, mechanical properties, dimensions, and heat number.
We verify hastelloy g35 composition in stages: controlled material ratios during smelting, chemical analysis to monitor composition, and PMI testing after completion. For customers requiring independent confirmation, third party laboratory testing can be arranged.
